UQK-651-C Float Level Controller Description
Product Name:
UQK-651-C Float Level ControllerModel No.:
UQK-651-C
JIANGSU YUANWANG INSTRUMENT UQK-651-C float level controller is widely used on the ships to monitor the high levels and low levels for tanks in engine room.
JIANGSU YUANWANG INSTRUMENT UQK-651-C Float Level Controller Technical Specifications
-
Origin:
Made In China -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Self Test Device:
The model UQK-651-C-Z with test device is available for option. -
Material:
Stainless Steel, Aluminium -
Application:
Bilge Well High Level Alarm, Bilge Tank High Level Alarm -
Standard Flange Size:
OD: 190mm, PCD: 150mm, Hole: 4x18mm -
Other Flange Size:
The UQK-652-C float level controller flange size can be made according to customers requirements. -
Control Range:
10 ~ 40 mm -
Mounting Type:
Vertical Mounting, Top Mounting -
Float Ball:
Φ50 , Φ60 , Φ76 -
Contact Capacity:
250V , 10A -
Protection:
IP66 , IP68 -
Explosion Proof:
The model UQK-652-C-B explosion proof grade Exd IICT6 is available for option. -
Working Temperature:
≤ 150℃ -
HS Code:
9026209000 -
Dimension:
Length x 190 x 190 mm -
Weight:
7Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
