JTW-ZD-5i Heat Detector Description
Product Name:
JTW-ZD-5i Heat DetectorModel No.:
JTW-ZD-5i
Wuxi brightsky JTW-ZD-5i heat detector is widely used on the ships for JB-QB-5Ei fire alarm system, JB-QB-5Si fire alarm control system and JB-QBC-5i fire alarm control system.
WUXI BRIGHTSKY JTW-ZD-5i HEAT DETECTOR Technical Specifications
-
Origin:
Made In China -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Features:
have CPU microchip, automatically discriminate fire alarm -
BUS:
two-wire bus, non-polarity design -
Coding Type:
adopt programmer to input address code -
Reliability:
electronic heat thermo unit, high sensitivity, high reliability -
CCS Approval No:
NJ07T00146 -
Operating Voltage:
DC 18~26V -
Monitoring Current:
≤380μA -
Alarm Current:
≤2mA -
Sofeware Version:
V1.0 -
Brand:
WUXI CHINA, BRIGHTSKY, BRIGHT SKY -
HS Code:
8531809090 -
Dimension:
88 x 88 x 34 mm -
Weight:
0.2Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
