Home > CHNBEL HIGH SPEED FUSE > NHV10S High Speed Fuse
NHV10S High Speed Fuse Description
Product Name:
NHV10S High Speed FuseModel No.:
NHV10S EV Fuses
CHNBEL NHV10S series electric vehicle EV fuses provide high performing DC protection of drive, auxiliary and battery systems. The fuses are also available as custom solutions for higher voltage and current ratings.
CHNBEL NHV10S HIGH SPEED FUSES Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
CHNBEL TYPE:
NHV10S, NHV10X, NHV10 -
NHV10S Diameter:
26mm -
NHV10S Length:
127mm -
NHV10S Centre Distance:
103mm -
Bolt Size:
M8 -
Rated Voltage:
1000VDC -
Rated Current:
35A, 40A, 50A, 60A, 70A, 80A, 90A, 100A, 150A, etc... -
Designed Standard:
JASO D622, ISO 8820-8, GB 31465, RoHS compliant, CE -
Circuit Protection:
CHNBEL NHV10S fuse is the ideal fusible circuit protection solution for battery and drive inverter. -
Circuit Protection:
CHNBEL NHV10S fuse also used as DC charging and short circuit back up protection. -
NHV10S Application:
Main and DC charging fuses, auxiliary fuse box and inverter fuses. -
HS Code:
8504409999 -
Weight:
0.2Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
