Home > CHNBEL HIGH SPEED FUSE > NHV10X High Speed Fuses
NHV10X High Speed Fuses Description
Product Name:
NHV10X High Speed FusesModel No.:
NHV10X EV Fuse
CHNBEL NHV10X series electric vehicle EV fuses provide high performing DC protection of drive, auxiliary and battery systems. The fuses are also available as custom solutions for higher voltage and current ratings.
CHNBEL NHV10X HIGH SPEED FUSES Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
CHNBEL TYPE:
NHV10S, NHV10X, NHV10 -
NHV10X Diameter:
38mm -
NHV10X Length:
136mm -
NHV10X Centre Distance:
107.5mm -
Bolt Size:
M10 -
Rated Voltage:
1000VDC -
Rated Current:
125A, 150A, 160A, 170A, 180A, 190A, 200A, 225A, etc... -
Designed Standard:
JASO D622, ISO 8820-8, GB 31465, RoHS compliant, CE -
Circuit Protection:
CHNBEL NHV10X fuse is the ideal fusible circuit protection solution for battery and drive inverter. -
Circuit Protection:
CHNBEL NHV10X fuse also used as DC charging and short circuit back up protection. -
NHV10X Application:
Main and DC charging fuses, auxiliary fuse box and inverter fuses. -
HS Code:
8504409999 -
Weight:
0.3Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
