KLY-NI96I-B Insulation Monitor Description
Product Name:
KLY-NI96I-B Insulation MonitorModel No.:
KLY-NI96I-B
SHANGHAI COMPLEE INSTRUMENT KLY-NI96I-B insulation monitor is widely used on the ships to monitoring the insulation resistance of ungrounded power network.
SHANGHAI COMPLEE INSTRUMENT KLY-NI96I-B Insulation Monitor Technical Specifications
-
Origin:
Made In China -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Voltage:
24V, 100V, 220V, 380V, 400V, 450V, etc... -
Related Type:
KLY-NI72I-A, KLY-NI96I-A, KLY-NI72I-B, KLY-NI96I-B, KLY-2NI96I, etc... -
Option:
SC: marine type, T: the monitor with self-detection -
Scale Develop Angle:
90°, 250° -
Accuracy Class:
1.5 -
Measurement Range:
0~1MΩ, 0~5MΩ, 0~10MΩ -
Alarm Preset Value:
10kΩ, 30kΩ, 60kΩ, 100kΩ, 200kΩ, 500kΩ, 1MΩ -
Relay Normally Close:
When the value is greater than alarm limit, relay operate, until the valuse is less than alarm limit. -
Protection:
IP44, IP56 -
HS Code:
9030332000 -
Dimension:
96 x 96 x 112 mm -
Weight:
0.5Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
