CWHD-100/24 Marine Steady Voltage Power Description
Product Name:
CWHD-100/24 Marine Steady Voltage PowerModel No.:
CWHD-100/24
WUHAN HANGDA ELECTRICAL SOURCE TECHNOLOGICAL CWHD-100/24 marine steady voltage power is widely used on the ships for charge and discharge panel, this CWHD-100/24 charger output current is 100A, the output current and output voltage can be adjust according to your requirements.
Wuhan Hangda Electrical Source Technological CWHD-100/24 Marine Steady Voltage Power Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
CWHD-100/24II:
Input voltage single phase. -
CWHD-100/24III:
Input voltage three phase. -
Serial Number:
Please provide serial number for repair or replacement this CWHD-100/24 charger. -
Input Voltage:
AC110V, AC220V, AC380V, AC440V -
Rated Frequency:
50/60HZ -
Output Voltage:
DC24V -
Current Adjust Range:
50~100A -
Protection:
IP20, IP22 -
Multi Functions:
Output over voltage alarm, output over current protect, over temperature protect. -
Warning:
Never charge a damaged battery. -
Working Temperature:
-10℃ ~ 50℃ -
HS Code:
8504409999 -
Dimension:
410 x 270 x 160 mm -
Weight:
15Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
