KEXUN Marine Auto Telephone Exchanger Description
Product Name:
KEXUN Marine Auto Telephone ExchangerModel No.:
KJ-1, KJ-2, KJ-3, KJ-4
JIAXING KEXUN ELECTRON KJ-1, KJ-2, KJ-3, KJ-4 marine auto telephone exchanger system is a new generation marine telephone that provides remote communication technology for all types of ships.
JIAXING KEXUN ELECTRON KJ-1, KJ-2, KJ-3, KJ-4 Marine Auto Telephone Exchanger Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Exchanger Capacity:
KJ-1: 24 lines, KJ-2: 48 lines, KJ-3: 88 ~ 128 lines, KJ-4: customize according to the number of users -
Installation Type:
Wall Type, Cabinet Type -
Function:
Two user call, Three user call, Conference call, Remote control broadcast, etc... -
Main Power Supply:
AC220V -
Emergency Power:
DC24V -
Signal Tone:
450 ± 25HZ Sine Wave -
Ringing Current Voltage:
75 ± 10V , 25 ± 3HZ -
Transmission Loss:
≤2dB -
Crosstalk Loss:
≥68dB -
Feedback Voltage:
24V -
Color:
Green Gray -
Protection:
IP22 -
HS Code:
8517621100 -
Dimension:
KJ-1: 527x314x187mm, KJ-2: 603x390x187mm, KJ-3: 663x442x315mm -
Weight:
KJ-1: 18Kg, KJ-2: 25Kg, KJ-3: 30Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
