UQK Type Overflow Annunciator Description

JIANGSU YUANWANG INSTRUMENT UQK type overflow annunciator is widely used on the ships to monitor the overfall pipeline.

JIANGSU YUANWANG INSTRUMENT UQK-65Y-AC-J Overflow Observation Alarm Technical Specifications

Origin:
Made In China
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
Material:
Stainless Steel
Application:
Engine room oil tank overflow pipe line.
Pipe Size:
DN32, DN40, DN50, DN65, DN80, DN100, DN125, DN150, DN200, DN250
Visible:
UQK-65Y-AC-J marine overflow observation alarm annunciator with visible window indication.
Alarm Output:
with float level controller, will output switch signal when overflow happens.
Connection Flange:
ANSI, JIS, DIN, etc...
Float Controller:
spare parts like float level controller is available for sells.
Medium Temperature:
≤ 100℃
HS Code:
9026209000
Dimension:
280 x 160 x 180 mm
Weight:
15Kg
Lead Time:
Stock Available.
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
