SCS-24160 KST Power Supply For Ship Description
Product Name:
SCS-24160 KST Power Supply For ShipModel No.:
SCS-24160
WUHAN CONSTANT SHIP ELECTRIC APPLIANCE SCS-24160 KST POWER SUPPLY FOR SHIP Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
SCS-24160-220 Voltage:
input voltage single phase 220VAC -
SCS-24160-230 Voltage:
input voltage three phase 220VAC -
SCS-24160-330 Voltage:
input voltage three phase 380VAC -
SCS-24160-430 Voltage:
input voltage three phase 440VAC -
Green Indication:
The working indicator light is on when the power supply is working normally. -
Red Indication:
The fault indicator light is on when the power supply has a fault or starts. -
Output Rated Voltage:
28.2VDC -
Voltage Adjustment:
output voltage adjustment range: 20~30VDC -
Current Adjustment:
output current adjustment range: 16 ~ 160A -
Application:
charge and discharge panel marine DC24V chargers -
Overvoltage Protection:
output overvoltage protection 30VDC -
Undervoltage Alarm:
output undervoltage alarm 21VDC -
Overheat Protection:
temperature inside the charger 85℃ -
Short Circuit Protection:
the charger is free from damage after short circuit and automatically recovers after repair -
Output Alarm:
the output alarm relay resets in the case of charger fault -
Heat Emission Method:
air cooling fan -
Protection:
IP20, IP22 -
Working Temperature:
-10℃ ~ 50℃ -
HS Code:
8504409999 -
Dimension:
530 x 280 x 230 mm -
Weight:
25Kg -
Lead Time:
stock available -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
