SCT-24100-230 KST Power Supply For Ship Description
Product Name:
SCT-24100-230 KST Power Supply For ShipModel No.:
SCT-24100-230
Wuhan constant ship electric appliance SCT-24100-230 KST power supply for ship is widely used on the ships for charge and discharge panel as marine battery charger & battery rectifier.
WUHAN CONSTANT SHIP ELECTRIC APPLIANCE SCT-24100-230 KST POWER SUPPLY FOR SHIP Technical Specifications
-
Origin:
MADE IN CHINA -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
SCT-24100-230 Voltage:
input voltage three phase 220VAC -
Green Indication:
The working indicator light is on when the power supply is working normally. -
Red Indication:
The fault indicator light is on when the power supply has a fault or starts. -
Output Voltage:
DC24V -
Float Charge:
output float charge voltage 26.4VDC -
Average Charge:
output average charge voltage 28.2VDC -
Output Current:
100A -
Application:
charge and discharge panel marine DC24V chargers -
Overvoltage Protection:
output overvoltage protection 30VDC -
Undervoltage Alarm:
output undervoltage alarm 21VDC -
Overheat Protection:
temperature inside the charger 85℃ -
Short Circuit Protection:
the charger is free from damage after short circuit and automatically recovers after repair -
Output Alarm:
the output alarm relay resets in the case of charger fault -
Heat Emission Method:
air cooling fan -
Protection:
IP20, IP22 -
Working Temperature:
-10℃ ~ 50℃ -
HS Code:
8504409999 -
Dimension:
410 x 260 x 110 mm -
Weight:
8Kg -
Lead Time:
stock available -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
