XY10-2760-1 Power Supply Module Charger Description

XIN YA CI DIAN XY10-2760-1 power supply module charger is widely used on the ships for charge and discharge panel.

XIN YA CI DIAN XY10-2760-1 POWER SUPPLY MODULE CHARGER Technical Specifications

Origin:
MADE IN CHINA
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
ACIN:
220V
Regulation:
with voltage regulation and current regulation function
Indicator:
normal, alarm, trouble
Input Voltage:
AC110V, AC220V, AC380V, AC440V
Rated Frequency:
50/60HZ
Output Voltage:
DC24V
Current Adjust Range:
5~60A
Protection:
IP20, IP22
Multi Functions:
Output over voltage alarm, output over current protect, over temperature protect.
Warning:
Never charge a damaged battery.
Working Temperature:
-10℃ ~ 50℃
HS Code:
8504409999
Dimension:
310 x 225 x 97 mm
Weight:
15Kg
Lead Time:
Stock Available.
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
