YSZK-01G-C-E pressure transmitter,JIANGSU YUANWANG INSTRUMENT

Home > YUANWANG INSTRUMENT > YSZK-01G-C-E Pressure Transmitter

YSZK-01G-C-E Pressure Transmitter Description

JIANGSU YUANWANG INSTRUMENT YSZK-01G-C-E marine pressure transmitter is widely used on ships to measure pressure of pipes and pumps.

JIANGSU YUANWANG INSTRUMENT YSZK-01G-C-E Marine Pressure Transmitter Technical Specifications

Origin:
Made In China
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
Related Type:
YSZK-01G-C, YSZK-01G-C-E, YSZK-01G-C-B, YSZK-01S-C-E, YSZK-01A-C-E
Measuring Range:
-0.1~0.1Mpa, 0~10Bar, 0~16Bar, 0~0.25Mpa, 0~0.4Mpa, 0~0.6Mpa, 0~1Mpa, 0~1.6Mpa, etc...
Material:
Stainless Steel
Features:
High measuring precision, dependable stability, convenient installation.
Power Supply:
DC24V
Measuring Accuracy:
±0.5％FS
Output Signal:
4 ~ 20 mA
Working Temperature:
-20 ~ 60℃
Connection Thread Size:
M20X1.5, G1/4", G1/2"
Explosion Proof:
Ex ia II CT3~6
Protection:
IP66
HS Code:
9026209000
Dimension:
140 x 50 x 30 mm
Weight:
0.5Kg
Lead Time:
Stock Available.
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
