YWK-50-C Pressure Switch Description
Product Name:
YWK-50-C Pressure SwitchModel No.:
YWK-50-C
YWK-50-C marine pressure switch is an electric switch that can make the circuit close or open following the change of pressure. It can be used to control the pressure water tank,hot water tank, air compressor, etc...
YWK-50-C Marine Pressure Switch Technical Specifications
-
Origin:
Made In China -
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc... -
Application:
YWK-50-C pressure switch can be used to control the pressure of gas, steam or liquid in ships. -
Pressure Control Range:
-0.1~0,0~0.1,0~0.2,0~0.3,0~0.5,0~0.8,0~1.0,0~1.5,0~2.0,0~3.0,0~4.0 Mpa -
Contact Capacity:
AC380V 3A , DC220V 2.5A -
Contact Connection:
1-2 makes on rising pressure, 1-3 makes on falling pressure -
Protection:
IP44 -
HS Code:
8536500090 -
Dimension:
224 x 104 x 57 mm -
Weight:
1Kg -
Lead Time:
Stock Available. -
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
