SD512-3/4 battery charger,zhenjiang tri-islands marine

Home > ZHENJIANG TRI ISLANDS > SD512-3/4 Battery Charger

SD512-3/4 Battery Charger Description

Zhenjiang tri-islands marine instruments and equipment SD512-3/4 battery charger automatically charges the battery with self protection.

ZHENJIANG TRI-ISLANDS MARINE INSTRUMENTS AND EQUIPMENT SD512-3/4 BATTERY CHARGER Technical Specifications

Origin:
MADE IN CHINA
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
Brand:
SANDAO, TRI-ISLANDS
Related Model:
SD512-3/4, SD512-3/120, SD512-3/130, SD512-3/160, SD512-3/220, SD512-3/230, SD512-3/260
Yellow Lamp:
charging, SD512-3/4 will charge automatically if the voltage of the battery is lower.
Green Lamp:
fully charged, SD512-3/4 will stop charge automatically if the voltage of the battery is charged to full.
Red Lamp:
failure, SD512-3/4 red lamp will flash there is open circuit, reverse polarity, short circuit.
Main Voltage:
AC220V
Charge Voltage:
DC12V
Charge Current:
2x10A
Protection:
IP56
Trouble Shooting:
SD512-3/4 red light is on, no battery connection, wrong polarity, short circuited battery cables.
Warning:
Always disconnect 220VAC before connecting or disconnecting batteries.
Working Temperature:
-25℃ ~ 40℃
HS Code:
8504409999
Dimension:
230 x 170 x 100 mm
Weight:
5Kg
Lead Time:
Stock Available.
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
