SD512-42 Battery Charger Description

Zhenjiang tri-islands marine instruments and equipment SD512-42 battery charger automatically charges the battery with self protection.

ZHENJIANG TRI-ISLANDS MARINE INSTRUMENTS AND EQUIPMENT SD512-42 BATTERY CHARGER Technical Specifications

Origin:
MADE IN CHINA
Market:
China, Singapore, Indonesia, Malaysia, Europe, Korea, U.A.E, India, etc...
Brand:
SANDAO, TRI-ISLANDS
Related Model:
SD512-42, SD512-2, SD512-3
Yellow Lamp:
charging, SD512-42 will charge automatically if the voltage of the battery is lower than 13.3V.
Green Lamp:
full, SD512-42 will stop charge automatically if the voltage of the battery is charged to 14.4V.
Red Lamp:
failure, SD512-42 red lamp will flash there is open circuit, reverse polarity, short circuit.
Main Voltage:
42VAC
Charge Voltage:
1x12VDC
Charge Current:
1x5ADC
Protection:
IP56
Trouble Shooting:
SD512-42 red light is on, no battery connection, wrong polarity, short circuited battery cables.
Warning:
Always disconnect 42VAC before connecting or disconnecting batteries.
Working Temperature:
-25℃ ~ 40℃
HS Code:
8504409999
Dimension:
108 X 74 X 81 mm
Weight:
2.5Kg
Lead Time:
Stock Available.
Class Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
